Soft Set Rivets
Identical in appearance to regular open-end rivets, Soft-Set Rivets incorporate a body and mandrel of special aluminum alloys. Breaking at a lower tensile point than regular mandrels, they afford a firm grip, but provide the more moderate pressures essential in fastening some of the more brittle materials.
Providing low cost fastenings, soft set rivets are ideal for a wide variety of applications. They are available in a wide variety of materials and combinations with dome, countersunk, or large-flange head styles. A universally accepted range of rivets suitable for most industrial riveting applications where the materials to be fastened do not have high load bearing requirements.
Rivet bodies are available in a range of materials for complete workpiece compatibility. The rivets are available in pure aluminum, aluminum 2.5%, 3.5% and 5.0% magnesium alloy, copper, mild steel, nickel-copper alloy, and stainless steel and are normally supplied with Break Stem mandrels which promote retention of the head of the mandrel in the set rivet body.
LBPP-04-02 Avdel LBPP Soft Set Rivets
LBPP-04-02, Avdel, LBPP Soft Set Rivets, Diameter: 0.125 Inch, Grip Range: 0.020-0.125 Inch, Dome Head, Body Material: Aluminum, Body Finish: Plain, Mandrel Material: Aluminum 5056, Mandrel Finish: Plain
Minimum Order Qty: 1 | Qty Interval: N/A
BSPN: BA-LBPP-04-02 | MPN: LBPP-04-02
Price: Request a Quote | Your Net Price: Request a Quote
Available Qty: -
Minimum Order Qty: 1
Qty Interval: 1
BSPN: BA-LBPP-04-02 | MPN: LBPP-04-02
Price: Request a Quote
Your Net Price: Request a Quote
Avg Lead Time For Backorders: Nil
Backorder Available Date: Nil
Available Qty: -
LBPP-04-02, Avdel, LBPP Soft Set Rivets, Diameter: 0.125 Inch, Grip Range: 0.020-0.125 Inch, Dome Head, Body Material: Aluminum, Body Finish: Plain, Mandrel Material: Aluminum 5056, Mandrel Finish: Plain
LBPP-04-04 Avdel LBPP Soft Set Rivets
LBPP-04-04, Avdel, LBPP Soft Set Rivets, Diameter: 0.125 Inch, Grip Range: 0.126-0.250 Inch, Dome Head, Body Material: Aluminum, Body Finish: Plain, Mandrel Material: Aluminum 5056, Mandrel Finish: Plain
Minimum Order Qty: 1 | Qty Interval: N/A
BSPN: BA-LBPP-04-04 | MPN: LBPP-04-04
Price: Request a Quote | Your Net Price: Request a Quote
Available Qty: -
Minimum Order Qty: 1
Qty Interval: 1
BSPN: BA-LBPP-04-04 | MPN: LBPP-04-04
Price: Request a Quote
Your Net Price: Request a Quote
Avg Lead Time For Backorders: Nil
Backorder Available Date: Nil
Available Qty: -
LBPP-04-04, Avdel, LBPP Soft Set Rivets, Diameter: 0.125 Inch, Grip Range: 0.126-0.250 Inch, Dome Head, Body Material: Aluminum, Body Finish: Plain, Mandrel Material: Aluminum 5056, Mandrel Finish: Plain
LBPP-04-06 Avdel LBPP Soft Set Rivets
LBPP-04-06, Avdel, LBPP Soft Set Rivets, Diameter: 0.125 Inch, Grip Range: 0.251-0.375 Inch, Dome Head, Body Material: Aluminum, Body Finish: Plain, Mandrel Material: Aluminum 5056, Mandrel Finish: Plain
Minimum Order Qty: 1 | Qty Interval: N/A
BSPN: BA-LBPP-04-06 | MPN: LBPP-04-06
Price: Request a Quote | Your Net Price: Request a Quote
Available Qty: -
Minimum Order Qty: 1
Qty Interval: 1
BSPN: BA-LBPP-04-06 | MPN: LBPP-04-06
Price: Request a Quote
Your Net Price: Request a Quote
Avg Lead Time For Backorders: Nil
Backorder Available Date: Nil
Available Qty: -
LBPP-04-06, Avdel, LBPP Soft Set Rivets, Diameter: 0.125 Inch, Grip Range: 0.251-0.375 Inch, Dome Head, Body Material: Aluminum, Body Finish: Plain, Mandrel Material: Aluminum 5056, Mandrel Finish: Plain
LBPP-04-08 Avdel LBPP Soft Set Rivets
LBPP-04-08, Avdel, LBPP Soft Set Rivets, Diameter: 0.125 Inch, Grip Range: 0.376-0.500 Inch, Dome Head, Body Material: Aluminum, Body Finish: Plain, Mandrel Material: Aluminum 5056, Mandrel Finish: Plain
Minimum Order Qty: 1 | Qty Interval: N/A
BSPN: BA-LBPP-04-08 | MPN: LBPP-04-08
Price: Request a Quote | Your Net Price: Request a Quote
Available Qty: -
Minimum Order Qty: 1
Qty Interval: 1
BSPN: BA-LBPP-04-08 | MPN: LBPP-04-08
Price: Request a Quote
Your Net Price: Request a Quote
Avg Lead Time For Backorders: Nil
Backorder Available Date: Nil
Available Qty: -
LBPP-04-08, Avdel, LBPP Soft Set Rivets, Diameter: 0.125 Inch, Grip Range: 0.376-0.500 Inch, Dome Head, Body Material: Aluminum, Body Finish: Plain, Mandrel Material: Aluminum 5056, Mandrel Finish: Plain
LBPP-05-06 Avdel LBPP Soft Set Rivets
LBPP-05-06, Avdel, LBPP Soft Set Rivets, Diameter: 0.156 Inch, Grip Range: 0.251-0.375 Inch, Dome Head, Body Material: Aluminum, Body Finish: Plain, Mandrel Material: Aluminum 5056, Mandrel Finish: Plain
Minimum Order Qty: 1 | Qty Interval: N/A
BSPN: BA-LBPP-05-06 | MPN: LBPP-05-06
Price: Request a Quote | Your Net Price: Request a Quote
Available Qty: -
Minimum Order Qty: 1
Qty Interval: 1
BSPN: BA-LBPP-05-06 | MPN: LBPP-05-06
Price: Request a Quote
Your Net Price: Request a Quote
Avg Lead Time For Backorders: Nil
Backorder Available Date: Nil
Available Qty: -
LBPP-05-06, Avdel, LBPP Soft Set Rivets, Diameter: 0.156 Inch, Grip Range: 0.251-0.375 Inch, Dome Head, Body Material: Aluminum, Body Finish: Plain, Mandrel Material: Aluminum 5056, Mandrel Finish: Plain
LBPP-06-04 Avdel LBPP Soft Set Rivets
LBPP-06-04, Avdel, LBPP Soft Set Rivets, Diameter: 0.187 Inch, Grip Range: 0.126-0.250 Inch, Dome Head, Body Material: Aluminum, Body Finish: Plain, Mandrel Material: Aluminum 5056, Mandrel Finish: Plain
Minimum Order Qty: 1 | Qty Interval: N/A
BSPN: BA-LBPP-06-04 | MPN: LBPP-06-04
Price: Request a Quote | Your Net Price: Request a Quote
Available Qty: -
Minimum Order Qty: 1
Qty Interval: 1
BSPN: BA-LBPP-06-04 | MPN: LBPP-06-04
Price: Request a Quote
Your Net Price: Request a Quote
Avg Lead Time For Backorders: Nil
Backorder Available Date: Nil
Available Qty: -
LBPP-06-04, Avdel, LBPP Soft Set Rivets, Diameter: 0.187 Inch, Grip Range: 0.126-0.250 Inch, Dome Head, Body Material: Aluminum, Body Finish: Plain, Mandrel Material: Aluminum 5056, Mandrel Finish: Plain
LBPP-06-06 Avdel LBPP Soft Set Rivets
LBPP-06-06, Avdel, LBPP Soft Set Rivets, Diameter: 0.187 Inch, Grip Range: 0.251-0.375 Inch, Dome Head, Body Material: Aluminum, Body Finish: Plain, Mandrel Material: Aluminum 5056, Mandrel Finish: Plain
Minimum Order Qty: 1 | Qty Interval: N/A
BSPN: BA-LBPP-06-06 | MPN: LBPP-06-06
Price: Request a Quote | Your Net Price: Request a Quote
Available Qty: -
Minimum Order Qty: 1
Qty Interval: 1
BSPN: BA-LBPP-06-06 | MPN: LBPP-06-06
Price: Request a Quote
Your Net Price: Request a Quote
Avg Lead Time For Backorders: Nil
Backorder Available Date: Nil
Available Qty: -
LBPP-06-06, Avdel, LBPP Soft Set Rivets, Diameter: 0.187 Inch, Grip Range: 0.251-0.375 Inch, Dome Head, Body Material: Aluminum, Body Finish: Plain, Mandrel Material: Aluminum 5056, Mandrel Finish: Plain
LBPP-110-04 Avdel LBPP Soft Set Rivets
LBPP-110-04, Avdel, LBPP Soft Set Rivets, Diameter: 0.109 Inch, Grip Range: 0.062-0.250 Inch, Dome Head, Body Material: Aluminum, Body Finish: Plain, Mandrel Material: Aluminum 5056, Mandrel Finish: Plain
Minimum Order Qty: 1 | Qty Interval: N/A
BSPN: BA-LBPP-110-04 | MPN: LBPP-110-04
Price: Request a Quote | Your Net Price: Request a Quote
Available Qty: -
Minimum Order Qty: 1
Qty Interval: 1
BSPN: BA-LBPP-110-04 | MPN: LBPP-110-04
Price: Request a Quote
Your Net Price: Request a Quote
Avg Lead Time For Backorders: Nil
Backorder Available Date: Nil
Available Qty: -
LBPP-110-04, Avdel, LBPP Soft Set Rivets, Diameter: 0.109 Inch, Grip Range: 0.062-0.250 Inch, Dome Head, Body Material: Aluminum, Body Finish: Plain, Mandrel Material: Aluminum 5056, Mandrel Finish: Plain
PAD25M3ABS Pop Soft Set Rivets
PAD25M3ABS, Pop, Soft Set Rivets, Diameter: 0.098 Inch, Grip Range: 0.126-0.189 Inch, Dome Head, Body Material: Aluminum, Body Finish: Plain, Mandrel Material: Aluminum, Mandrel Finish: Plain
Minimum Order Qty: 1 | Qty Interval: N/A
BSPN: BA-PAD25M3ABS | MPN: PAD25M3ABS
Price: Request a Quote | Your Net Price: Request a Quote
Available Qty: -
Minimum Order Qty: 1
Qty Interval: 1
BSPN: BA-PAD25M3ABS | MPN: PAD25M3ABS
Price: Request a Quote
Your Net Price: Request a Quote
Avg Lead Time For Backorders: Nil
Backorder Available Date: Nil
Available Qty: -
PAD25M3ABS, Pop, Soft Set Rivets, Diameter: 0.098 Inch, Grip Range: 0.126-0.189 Inch, Dome Head, Body Material: Aluminum, Body Finish: Plain, Mandrel Material: Aluminum, Mandrel Finish: Plain
PAD25M4ABS Pop Soft Set Rivets
PAD25M4ABS, Pop, Soft Set Rivets, Diameter: 0.098 Inch, Grip Range: 0.187-0.252 Inch, Dome Head, Body Material: Aluminum, Body Finish: Plain, Mandrel Material: Aluminum, Mandrel Finish: Plain
Minimum Order Qty: 1 | Qty Interval: N/A
BSPN: BA-PAD25M4ABS | MPN: PAD25M4ABS
Price: Request a Quote | Your Net Price: Request a Quote
Available Qty: -
Minimum Order Qty: 1
Qty Interval: 1
BSPN: BA-PAD25M4ABS | MPN: PAD25M4ABS
Price: Request a Quote
Your Net Price: Request a Quote
Avg Lead Time For Backorders: Nil
Backorder Available Date: Nil
Available Qty: -
PAD25M4ABS, Pop, Soft Set Rivets, Diameter: 0.098 Inch, Grip Range: 0.187-0.252 Inch, Dome Head, Body Material: Aluminum, Body Finish: Plain, Mandrel Material: Aluminum, Mandrel Finish: Plain
PAD25M5ABS Pop Soft Set Rivets
PAD25M5ABS, Pop, Soft Set Rivets, Diameter: 0.098 Inch, Grip Range: 0.252-0.315 Inch, Dome Head, Body Material: Aluminum, Body Finish: Plain, Mandrel Material: Aluminum, Mandrel Finish: Plain
Minimum Order Qty: 1 | Qty Interval: N/A
BSPN: BA-PAD25M5ABS | MPN: PAD25M5ABS
Price: Request a Quote | Your Net Price: Request a Quote
Available Qty: -
Minimum Order Qty: 1
Qty Interval: 1
BSPN: BA-PAD25M5ABS | MPN: PAD25M5ABS
Price: Request a Quote
Your Net Price: Request a Quote
Avg Lead Time For Backorders: Nil
Backorder Available Date: Nil
Available Qty: -
PAD25M5ABS, Pop, Soft Set Rivets, Diameter: 0.098 Inch, Grip Range: 0.252-0.315 Inch, Dome Head, Body Material: Aluminum, Body Finish: Plain, Mandrel Material: Aluminum, Mandrel Finish: Plain
PAD30M3ABS Pop Soft Set Rivets
PAD30M3ABS, Pop, Soft Set Rivets, Diameter: 0.118 Inch, Grip Range: 0.126-0.189 Inch, Dome Head, Body Material: Aluminum, Body Finish: Plain, Mandrel Material: Aluminum, Mandrel Finish: Plain
Minimum Order Qty: 1 | Qty Interval: N/A
BSPN: BA-PAD30M3ABS | MPN: PAD30M3ABS
Price: Request a Quote | Your Net Price: Request a Quote
Available Qty: -
Minimum Order Qty: 1
Qty Interval: 1
BSPN: BA-PAD30M3ABS | MPN: PAD30M3ABS
Price: Request a Quote
Your Net Price: Request a Quote
Avg Lead Time For Backorders: Nil
Backorder Available Date: Nil
Available Qty: -
PAD30M3ABS, Pop, Soft Set Rivets, Diameter: 0.118 Inch, Grip Range: 0.126-0.189 Inch, Dome Head, Body Material: Aluminum, Body Finish: Plain, Mandrel Material: Aluminum, Mandrel Finish: Plain
General Features of Soft-Set Rivets
- Wide range of diameters and lengths suitable for material thicknesses up to 26mm
- Low in-place costs
- Fast assembly
- Lightweight
- Easily portable tools
- Vibration-proof assembly
- No surface marring
- Exceptional versatility
- High grip and pull-up strengths
- Tamper proof
- Increased design flexibility
